Especificação
Display |
|
LCD |
17″ TFT LCD |
Resolution |
Up to 1280 x 1024 |
Active Area |
377.920 (H) x 270.336 (V) |
Pixel Pitch |
0.264 (H) x 0.264 (V) |
Pixel Arrangement |
RGB Vertical Stripe |
Viewing Angle |
80/80/80/80 degree (U/D/L/R) |
Contrast Ratio |
1000 : 1 |
Response Time |
3.5 ms (Raising)/1.5 ms (Falling) |
Brightness |
250 cd/m2 |
Touch |
|
Touch Type |
Resistive touch for TM-7117E
|
Interface |
USB |
General Specification |
|
Display Interface |
VGA |
Power Supply |
12V/18W |
Dimension (W x D x H in mm) |
401 x 286 x 385 |
Weight (N.W. in kg) |
6.82 |
Operating Condition |
Temp： 0~50ﾟ
|
Support |
|
System Supported |
N/A |
VESA Mounting Support |
Optional, VESA Mounting Kit (WB-6000V-B) |
Options |
|
Options |
MSR & Key Pad Side Attachment |
* The product information and specifications are subject to change without prior notice. |
|
Download
Upload Date |
Description |
Version |
Size |
Language |
|
2017-12-19 |
User Manual for MT-4308W/4310W (EN) |
B0 |
2.9 MB |
English |
|
